BioHorizons External (Maestro) main image

External (Maestro) By BioHorizons®

Technical Features

Material: Titanium Alloy
Level: Bone Level
Connection Type: External
Connection Shape: Hexagon
Head Shape: Wide
Head Microthreads: No
Body Shape: Tapered Apex
Body Threads: V Shaped
Apex Shape: Flat
Apex Hole: No Hole
Apex Grooves: Yes

PDF Catalog Order Compatible Components Contact us

Identify a dental implant

Learn more

Connection

External Hexagon

Screwdriver

Platforms

3.7mm
4.2mm

Platform specifications and compatibilities

Dimensions

Length \ Diameter	3.50mm	4.00mm
7.00mm	3507D3 3507D3*	4007D3 4007D3*
9.00mm	3509D3	4009D3
10.50mm	35105D3	40105D3
12.00mm	3512D3	4012D3
15.00mm	3515D3	4015D3

Compatible Components

Components compatible with BioHorizons® External (Maestro)®

Browse compatible components

Description

External (Maestro) is a standard dental implant produced by BioHorizons. It's a bone level implant. Its connection is external, with a hexagon shape with none. Its body is tapered apex with v shaped threads. Its head is wide. Its apex has a flat shape, doesn't have a hole, and has grooves. It is made of titanium alloy. This implant model is quite old. It requires a screwdriver of hexagon shape. For more details, please refer to the catalog. BioHorizons also offers 24 other implant models.
Specs:
Resorbable Blast Hydroxylapatite Texturing (RBT) Coating (HA) Roughened High-density TiO2 surface Diameter x Length crystalline coating 3507D3* 3.5mm x 7mm NA 3509D3 3.5mm x 9mm NA 35105D3 3.5mm x 10.5mm NA 3512D3 3.5mm x 12mm NA 3515D3 3.5mm x 15mm NA 4007D3* 4.0mm x 7mm 4007D4* 4009D3 4.0mm x 9mm 4009D4 40105D3 4.0mm x 10.5mm 40105D4 4012D3 4.0mm x 12mm 4012D4 4015D3 4.0mm x 15mm 4015D4 5007D3* 5.0mm x 7mm 5007D4* 5009D3 5.0mm x 9mm 5009D4 50105D3 5.0mm x 10.5mm 50105D4 5012D3 5.0mm x 12mm 5012D4 5015D3 5.0mm x 15mm 5015D4 6007D3* 6.0mm x 7mm 6007D4* 6009D3 6.0mm x 9mm 6009D4 60105D3 6.0mm x 10.5mm 60105D4 6012D3 6.0mm x 12mm 6012D4 6015D3 6.0mm x 15mm 6015D4 Each implant is packaged with the 3 inOne Abutment, Cover Screw and Abutment Screw. Implants Choice of RBT or HA surface treatment (except 03. 5mm: RBT only). Order by length and diameter. Titanium Alloy [Ti-6AI-4V]. Resorbable Blast Hydroxylapatite Texturing (RBT) Coating (HA) Roughened High-density TiO2 surface crystalline co…

Components compatible with BioHorizons® External (Maestro)®:
Impression copings, Implant analogs, Abutments, Straight multi unit abutments, Scan bodies, Titanium bases, Locator, Locator R-TX, Ball attachment, Screws, Screwdrivers. Available for different platforms.
