Torque Interno TI Cônico By Dentfix®
Technical Features
- Level: Bone Level
- Connection Type: External
- Connection Shape: Hexagon
- Head Shape: Straight
- Head Microthreads: No
- Body Shape: Tapered Apex
- Body Threads: V Shaped
- Apex Shape: Dome
- Apex Hole: No Hole
- Apex Grooves: Yes
Identify a dental implant
Learn moreScrewdrivers
Dimensions
| Length \ Diameter | 3.50mm | 4.30mm | 5.00mm |
|---|---|---|---|
| 10.00mm | IASC-3510(P:4.10mm) | IASC-4310(P:4.10mm) | IASC-5010(P:4.10mm) |
| 11.50mm | IASC-3511(P:4.10mm) | IASC-4311(P:4.10mm) | IASC-5011(P:4.10mm) |
| 13.00mm | IASC-3513(P:4.10mm) | IASC-4313(P:4.10mm) | IASC-5013(P:4.10mm) |
| 15.00mm | IASC-3515(P:4.10mm) | IASC-4315(P:4.10mm) | IASC-5015(P:4.10mm) |
Compatible Components
Components compatible with Dentfix® Torque Interno TI Cônico®
Description
Torque Interno TI Cônico is a standard dental implant produced by Dentfix. Its connection is external, with a hexagon shape with none. It's a bone level implant. Its body is tapered apex with v shaped threads. Its head is straight. Its apex has a dome shape, doesn't have a hole, and has grooves. It is available in 3 different diameters and 4 different lengths. It requires a screwdriver of hexagon shape. For more details, please refer to the catalog. Dentfix also offers 5 other implant models.
Components compatible with Dentfix® Torque Interno TI Cônico®:
Impression copings, Implant analogs, Abutments, Straight multi unit abutments, Scan bodies, Titanium bases, Locator, Locator R-TX, Ball attachment, Screws, Screwdrivers.
Available for different platforms.
