SlimLine By Dentium®

Technical Features

Level: Bone Level
Connection Type: Internal
Connection Shape: Hexagon
Head Shape: Flared
Head Microthreads: No
Body Shape: Tapered
Body Threads: Buttress
Apex Shape: Dome
Apex Hole: No Hole
Apex Grooves: No

PDF Catalog

Identify a dental implant

Learn more

Dimensions

Length \ Diameter	2.65mm	2.80mm
6.00mm	IUS301506(P:2.85mm) IUS401506(P:3.80mm) IUS251506(P:2.40mm) IUS201506(P:2.00mm) IUS351506(P:3.40mm)	IBS202006(P:2.00mm) IBS252006(P:2.40mm) IBS302006(P:2.85mm) IBS352006(P:3.40mm) IBS402006(P:3.80mm)
8.00mm	IUS301508(P:2.85mm) IUS201508(P:2.00mm) IUS351508(P:3.40mm) IUS401508(P:3.80mm) IUS251508(P:2.40mm)	IBS402008(P:3.80mm) IBS302008(P:2.85mm) IBS352008(P:3.40mm) IBS202008(P:2.00mm) IBS252008(P:2.40mm)
10.00mm	IUS351510(P:3.40mm) IUS251510(P:2.40mm) IUS401510(P:3.80mm) IUS201510(P:2.00mm) IUS301510(P:2.85mm)	IBS252010(P:2.40mm) IBS402010(P:3.80mm) IBS302010(P:2.85mm) IBS202010(P:2.00mm) IBS352010(P:3.40mm)
12.00mm	IUS301512(P:2.85mm) IUS201512(P:2.00mm) IUS351512(P:3.40mm) IUS251512(P:2.40mm) IUS401512(P:3.80mm)	IBS302012(P:2.85mm) IBS352012(P:3.40mm) IBS252012(P:2.40mm) IBS402012(P:3.80mm) IBS202012(P:2.00mm)
14.00mm	IUS201514(P:2.00mm) IUS351514(P:3.40mm) IUS401514(P:3.80mm) IUS301514(P:2.85mm) IUS251514(P:2.40mm)	IBS202014(P:2.00mm) IBS352014(P:3.40mm) IBS252014(P:2.40mm) IBS302014(P:2.85mm) IBS402014(P:3.80mm)

Description

SlimLine is a narrow dental implant produced by Dentium. Its connection is internal, with a hexagon shape with none. It's a bone level implant. Its head is flared. Its body is tapered with buttress threads. Its apex has a dome shape, doesn't have a hole, and doesn't have grooves. For more details, please refer to the catalog. Dentium also offers 16 other implant models.
