All Spiral By Eckermann®

Technical Features

Level: Bone Level
Connection Type: External
Connection Shape: Square
Head Shape: Straight
Head Microthreads: No
Body Shape: Tapered
Body Threads: V Shaped
Apex Shape: Dome
Apex Hole: No Hole
Apex Grooves: No

PDF Catalog

Identify a dental implant

Learn more

Screwdriver

Platforms

default

Dimensions

Length \ Diameter	3.00mm	3.50mm	4.00mm	4.50mm	5.00mm
8.00mm	IS 233008	IS 233508	IS 234008	IS 234508	IS 235008
10.00mm	IS 233010	IS 233510	IS 234010	IS 234510	IS 235010
11.50mm	IS 233011	IS 233511	IS 234011	IS 234511	IS 235011
13.00mm	IS 233013	IS 233513	IS 234013	IS 234513	IS 235013
15.00mm	IS 233015	IS 233515	IS 234015	IS 234515	IS 235015
17.00mm	IS 233017	IS 233517	IS 234017	IS 234517	IS 235017

Description

All Spiral is a standard dental implant produced by Eckermann. It's a bone level implant. Its connection is external, with a square shape with morse taper. Its body is tapered with v shaped threads. Its head is straight. Its apex has a dome shape, doesn't have a hole, and doesn't have grooves. It is available in 5 different diameters and 6 different lengths. This implant model is quite old. It requires a screwdriver of hexagon shape. For more details, please refer to the catalog. Eckermann also offers 15 other implant models.
Specs:
Implante All Spirale R REF. 3,0 8 mm. IS 233008 10 mm. IS 233010 11,5 mm. IS 233011 13 mm. is 233013 15 mm. IS 233015 17 mm. is 233017 0 3,5 8 mm. IS 233508 10 mm. is 233510 11,5 mm. IS 233511 13 mm. IS 233513 15 mm. IS 233515 17 mm. IS 233517 0 4,0 8 mm. IS 234008 10 mm. is 234010 11,5 mm. IS 234011 13 mm. IS 234013 15 mm. IS 234015 17 mm. IS 234017 0 4,5 8 mm. is 234508 10 mm. IS 234510 11,5 mm. IS 234511 13 mm. IS 234513 15 mm. IS 234515 17 mm. IS 234517 0 5,0 8 mm. IS 235008 10 mm. IS 235010 11,5 mm. IS 235011 13 mm. IS 235013 15 mm. IS 235015 17 mm. IS 235017
