External Hex By Eckermann®

Technical Features

Level: Bone Level
Connection Type: External
Connection Shape: Hexagon
Head Shape: Straight
Head Microthreads: No
Body Shape: Tapered
Body Threads: V Shaped
Apex Shape: Dome
Apex Hole: No Hole
Apex Grooves: No

PDF Catalog Order Compatible Components Contact us

Identify a dental implant

Learn more

Connection

External Hexagon

Screwdrivers

Platforms

default

Platform specifications and compatibilities

Dimensions

Length \ Diameter	3.00mm	3.50mm	4.00mm
8.00mm	IHC 073008	IHC 073508	IHC 074008
10.00mm	IHC 073010	IHC 073510	IHC 074010
11.50mm	IHC 073011	IHC 073511	IHC 074011
13.00mm	IHC 073013	IHC 073513	IHC 074013
15.00mm	IHC 073015	IHC 073515	IHC 074015
17.00mm	IHC 073017	IHC 073517	IHC 074017

Compatible Components

Components compatible with Eckermann® External Hex®

Browse compatible components

Description

External Hex is a standard dental implant produced by Eckermann. It's a bone level implant. Its connection is external, with a hexagon shape with none. Its body is tapered with v shaped threads. Its head is straight. Its apex has a dome shape, doesn't have a hole, and doesn't have grooves. It is available in 3 different diameters and 6 different lengths. It requires a screwdriver of hexagon shape. For more details, please refer to the catalog. Eckermann also offers 15 other implant models.

Components compatible with Eckermann® External Hex®:
Impression copings, Implant analogs, Abutments, Straight multi unit abutments, Scan bodies, Titanium bases, Locator, Locator R-TX, Ball attachment, Screws, Screwdrivers. Available for different platforms.
