Replant By Implant Direct®

Technical Features

Level: Bone Level
Connection Type: Internal
Connection Shape: Tri lobe
Head Shape: Straight
Head Microthreads: Yes
Body Shape: Tapered
Body Threads: V Shaped
Apex Shape: Dome
Apex Hole: No Hole
Apex Grooves: Yes

PDF Catalog Order Compatible Components Contact us

Identify a dental implant

Learn more

Connection

Internal Tri lobe

Screwdriver

Platforms

3.5mm
4.3mm
5mm
6mm

Platform specifications and compatibilities

Dimensions

Length \ Diameter	3.50mm	4.30mm	5.00mm	6.00mm
8.00mm	603508(P:3.50mm)	604308(P:4.30mm)	605008(P:5.00mm)	606008(P:6.00mm)
10.00mm	603510(P:3.50mm)	604310(P:4.30mm)	605010(P:5.00mm)	606010(P:6.00mm)
11.50mm	603511(P:3.50mm)	604311(P:4.30mm)	605011(P:5.00mm)	606011(P:6.00mm)
13.00mm	603513(P:3.50mm)	604313(P:4.30mm)	605013(P:5.00mm) ✔	606013(P:6.00mm)
16.00mm	603516(P:3.50mm)	604316(P:4.30mm)	605016(P:5.00mm)	606016(P:6.00mm)

Compatible Components

Components compatible with Implant Direct® Replant®

Browse compatible components

Description

Replant is a standard dental implant produced by Implant Direct. Its connection is internal, with a tri lobe shape with none. It's a bone level implant. Its head is straight and has microthreads. Its body is tapered with v shaped threads. Its apex has a dome shape, doesn't have a hole, and has grooves. It is available in 4 different diameters and 5 different lengths.It is available in 4 different platforms. It requires a screwdriver of hexagon shape. For more details, please refer to the catalog. Implant Direct also offers 25 other implant models.
Specs:
SBM Surface Implants Incl. Carrier/Transfer, Duel-Grip" Fixation and Cover Screw 3.5mmD Code Diameter Length Platform 603508 3.5mmD 8.0mmL 3.5mmD 603510 3.5mmD 10.0mmL 3.5mmD 603511 3.5mmD 11.5mml 3.5mmD 603513 3.5mmD 13.0mml 3.5mmD 603516 3.5mmD 16.0mml 3.5mmD 4.3mmD Code Diameter Length Platform 604308 4.3mmD 8.0mmL 4.3mmD 604310 4.3mmD 10.0mmL 4.3mmD 604311 4.3mmD 11.5mmL 4.3mmD 604313 4.3mmD 13.0mml 4.3mmD 604316 4.3mmD 16.0mml 4.3mmD 5.0mmD Code Diameter Length Platform 605008 5.0mmD 8.0mml 5.0mmD 605010 5.0mmD 10.0mml 5.0mmD 605011 5.0mmD 11.5mml 5.0mmD 605013 5.0mmD 13.0mml 5.0mmD 605016 5.0mmD 16.0mml 5.0mmD 6.0mmD Code Diameter Length Platform 606008 6.0mmD 8.0mml 6.0mmD 606010 6.0mmD 10.0mml 6.0mmD 606011 6.0mmD 11.5mml 6.0mmD 606013 6.0mmD 13.0mml 6.0mmD 606016 6.0mmD 16.0mml 6.0mmD

Components compatible with Implant Direct® Replant®:
Impression copings, Implant analogs, Abutments, Straight multi unit abutments, Scan bodies, Titanium bases, Locator, Locator R-TX, Ball attachment, Screws, Screwdrivers. Available for different platforms.
