Sendax MDI Standard (O-Ball Head) By IMTEC®
Technical Features
- Material: Titanium Alloy
- Level: Tissue Level
- Connection Type: Custom
- Connection Shape: One piece Ball
- Head Shape: Straight
- Head Microthreads: Yes
- Body Shape: Tapered Apex
- Body Threads: Buttress
- Apex Shape: Cone
- Apex Hole: No Hole
- Apex Grooves: No
Identify a dental implant
Learn moreDimensions
| Length \ Diameter | 1.80mm | 2.10mm |
|---|---|---|
| 10.00mm | S1810-OB | S1810-IOB |
| 13.00mm | S1813-OB | S1813-IOB |
| 15.00mm | S1815-OB | S1815-IOB |
| 18.00mm | S1818-OB | S1818-IOB |
Description
Sendax MDI Standard (O-Ball Head) is a narrow dental implant produced by IMTEC. It's a tissue level implant. Its connection is custom, with a one piece ball shape with none. Its head is straight and has microthreads. Its body is tapered apex with buttress threads. Its apex has a cone shape, doesn't have a hole, and doesn't have grooves. It is made of titanium alloy. This implant model is quite old. For more details, please refer to the catalog. IMTEC also offers 20 other implant models.
Specs:
Standard Thread Design, O-Ball Prosthetic Head* Size Item 10mm S1810-OB 1.8mm 13mm S1813-OB 15mm S1815-OB 18mm S1818-OB "Utilizes the 5118 MDI Classic O-Ball Head Analog on page 9 Standard Thread Design, O-Ball Prosthetic Head* A Size Item 2.1mm 10mm S1810-IOB 13mm S1813-IOB 15mm S1815-IOB 18mm S1818-IOB "Utilizes the 5118 MDI Classic O-Ball Head Analog on page 9 4
